Description

Notice

  • For safety issue, please do not use headset during charging.
  • Please fully charge the headset before use.
  • Please remove the protection plastic cover of optical cable before use.
  • To eliminate cutting in and out and sound robotic caused by transmission interruption with your WIFI & Bluetooth device:
  1. Try using cable internet connection for console / PC
  2. Limited the use of Bluetooth devices
  3. Place the transmitter dongle as far away from consoles as possible (don’t put it on top of console).

Specification:

Headset

  • Working voltage: 3.5-4.2V
  • Working current: 75 mA
  • Lithium battery: 1200 mAH
  • Working hours: 15h
  • Charging time: 5h
  • Frequency range: 2.400-2.483Ghz
  • Frequency space:2MHz
  • Transmit rate: 3 dB
  • Sampling frequency: 48 KHz
  • Modulate mode: GFSK
  • Receiving sensitivity: -85dB
  • SNR: 85 dB
  • Speaker size: 40mm
  • Speaker impedance: 32Ω
  • Frequency response: 20~20 KHz

Microphone

  • Microphone sizes: 6.0*5mm
  • Microphone sensitivity: -58dB
  • Microphone direction: Omni directional
  • Microphone frequency response: 100Hz-8 KHz

Packing contents:

  • 1 x Transmitter
  • 1 x Wireless headset
  • 1 x 3.5-2.5 cable
  • 1 x 3.5-3.5 cable
  • 2 x USB-USB Micro cable
  • 1 x Fibre-optic cable
  • 1 x Detachable Microphone
  • 1 x Manual guide
