Description
Rogogo PCI-E to USB 3.0 4 Ports PCI Express Expansion Card.
Specifications:
• External Ports: 4x USB 3.0
• Internal Ports: 1x SATA 15Pin Power Connector
• Host Interface: PCI Express (PCI-E)
• Data Transfer Rate: Up to 5.0 Gbps
• Output: 5V/1A MAX (each USB port) Expand Additional Superspeed 4 usb 3.0 ports for your PC with quick and easy installation.
Features:
• Supports 4 downstream ports for all speeds
• Supports the following speed data rates as follows:
• Low-speed (1.5Mb/s) / Full-speed (12Mb/s) / High-speed (480Mb/s) / Super-speed (5Gb/s)
• Supports simultaneous operation of multiple USB 3.0/2.0/1.1 devices
• Hot-swapping feature allows you to connect/disconnect devices without powering down the system
• Support UASP: 70% Faster than traditional USB 3.0
• SuperSpeed USB 3.0: accelerated file access and transfer speeds, up to 5 Gbps;
• Supports simultaneous operation of multiple USB 3.0, USB 2.0 and USB 1.1 devices
• Operating Systems: Windows XP, Vista and Windows 7 (with included drivers) Windows 8/8.1/10
No additional drivers are needed for Win8/8.1/10
Package includes:
•1 x 4 port pci-e to usb 3.0 expansion card
•1 x 4 pin to 2×4 pin Y-cable
•1 x 15 pin to 15 pin + 4pin Y-cable
•1 x driver CD
Attention:
• If there is no free 4 pin Molex plug or the cable is too short in your pc,please use the enclosed 4pin to 2×4 pin Y-cable
• If there is only 15 pin sata plug in your pc,please use the enclosed 15pin to 15pin+4pin Y-cable Notification:
• The actual transmission speed is limited by the setting of the device connected
• This PCI-E card is only compatible with standard-sized tower cases (not mini computers)
